We produce precise products with state-of-the-art processing equipment and secure a position in the future industry based on customer trust.
5-Axes
-
Model
5-Axes Versa Tech V140N -
Manufacturers
MAZAK(Japan) -
Characteristics
High Accuracy ServomotorAxis-Heat Displacement Correction System -
Max Storke(m)
X-axis : 11,000mm Y-axis : 4,600mm Z-axis : 710mm W-axis : 1,250mm B-axis : ±100˚ C-axis : ±180˚ (360˚ 무한) SPINDLE Max. RPM : 10,000 r/min SPINDLE Torque : 344 N-m
G750T
-
Model
G750T -
Manufacturers
GROB(Germany) -
Max Storke(m)
X/Y/Z-axis : 1,000/1,100/1,170mm -
Max speed (m/min)
X : 60 Y : 50 Z : 75 -
Interface Diameter
1,280mm -
Max speed
14,500 r/min -
SWIVELING ANGLE A-axis
-180˚/+45˚
G150
-
Model
G150 -
Manufacturers
GROB(Germany) -
Max Storke(m)
X/Y/Z-axis : 450/670/665mm -
Max speed (m/min)
X : 50 Y : 40 Z : 60 -
Interface Diameter
580mm -
Max speed (m/min)
16,000 r/min -
SWIVELING ANGLE A-axis
-185˚/+45˚
CNC
-
Model
CNC Lathe P/T-9NAX 3000 -
Manufacturers
Hankook Machine(Korea) -
Table size(mm)
2,000 ~ 8,000 -
Max speed (m/min)
7~800 -
Motor power(Kw)
37
DOOSAN MYNX6500/50
-
Model
MYNX6500/50 -
Manufacturers
DOOSAN -
Table size(mm)
1,400X6,700 -
Max Storke(m)
X/Y/Z-axis : 1,270/670/625 -
Max speed (m/min)
6,000 r/min
N130F
-
Model
3축가공기(N130F) -
Manufacturers
NAMBUK -
Max Storke(m)
500/400/300 -
RPM
13,000rpm -
axis
3axis
SPT-V18
-
Model
3 Axis processing machine(SPT-V18) -
Manufacturers
HYUNDAI -
Transfer distance (X/Y/Z)
560/410/400 -
RPM
9,000rpm -
axis
3axis
SPT-V32405
-
Model
3 Axis processing machine(SPT-V32405) -
Manufacturers
HYUNDAI -
Transfer distance (X/Y/Z)
1000/700/460 -
RPM
6,000rpm -
axis
3axis
